How do you adjust a comet torque converter?

Adjusting your Torque Converter in 4 Easy Steps

Step 1 – Remove the Nut, Snap Ring, Cam and Spring. In order to adjust your torque converter, you must get access to the spring.
Step 2 – Adjust the Spring.
Step 3 – Reassemble the Nut, Snap Ring, Cam and Spring.
Step 4 – Preload the Spring and Assemble the Snap Ring and Nut.

How much horsepower can a 30 Series torque converter handle?

Comet 30 Series Torque Converter System (Asymmetrical) Comet 30 series torque converter system is for 2 or 4 cycle engines up thru 8 hp. The model 30 uses a 3/4″ top width asymmetric belt. Drive clutches are available for both 3/4″ and 1″ bore (with 3/16-1/4 keyway).

Why does my go-kart jerk?

You should know that rusted, worn, or damaged throttle cables can cause poor engine response, giving you go-kart acceleration problems such as jerks or delayed acceleration. Installing your throttle cables incorrectly can also cause similar effects which will be noticeable when you start pushing down the gas pedal.

How does a comet clutch work?

How does a Comet torque converter work? The drive clutch is activated by centrifugal force from the engine crankshaft. The movable sheave of the clutch is forced in as the RPM of the engine is increased. As this happens, the speed from the engine transferred to the final drive is increased.

Why is my go kart not accelerating?

One of the more common reasons for go-kart acceleration problems is the result of a clogged or damaged carburetor. Therefore, you should check if your carb is running optimally. The carburetor is responsible for mixing a proper air to fuel ratio before the flows into the engine.

Why does my go kart keep turning off?

If your engine is starting but then shutting off check for these issues: A bad spark plug or loose plug wire will prevent the engine from running. A clogged or wet air filter will shut the engine down.

Are Comet torque converters symmetric or asymmetric?

Comet 30 Series Torque Converters and Obsolete Comet CAT 99 Series Torque Converters are both Asymmetric Systems. Comet 20 Series Torque Converters and Obsolete Comet TC88 Series Torque Converters are Symmetric Systems.

What size torque converter do I need for a 500 Comet?

Comet 500 series torque converter system is based on the old salsbury clutches. It will handle up to 25hp 2 cycle engines and 16 hp 4 cycle engines. The drive clutch comes with either a 3/4″ or a 1″ bore. The driven clutch comes in either a 7-1/2″ or a 8-1/2″ diameter unit, the bore size can be either 3/4″ or 1″.

What are the specs of a comet 30 series driven pulley?
