IDE ribbon cables have either 40 or 80 wires. There is a connector at each end of the cable and another one about two-thirds of the distance from the motherboard connector.
How does IDE cable select work?
Cable select, also referred to by the acronym CS, is a disk drive jumper setting which automatically sets the priority of a disk drive by its position on its data cable. For cable select to work, an IDE/EIDE drive must have its jumpers set to CS and be using a cable that supports cable select.
How long is the Xbox IDE cable?
The stock IDE cable in the Xbox is a 40 wire ribbon cable and unfortunately will not work with any IDE to SATA bridge adapter. You have to replace it with an 80 wire IDE cable to work. The stock cable is 24 inches long, however an 18 inch one will work with some finessing.
What is the purpose of the extra 40 wires in an 80-wire IDE cable?
The extra wires in an 80-wire cable aren’t used to pass traffic, but they can reduce the amount of crosstalk between the signal wires. This becomes especially important as the speed increases.
How many pins are in a 40 conductor IDE cable?
Parallel ATA
| Production history | |
|---|---|
| Cable | 40 or 80 conductor ribbon cable |
| Pins | 40 |
| Data | |
| Width | 16 bits |
What is TSOP Xbox?
TSOP flashing: reflashing the onboard BIOS chip with a hacked BIOS to circumvent the security mechanisms. The Xbox BIOS is contained on a commodity EEPROM (the ‘TSOP’), which can be made writable by the Xbox by bridging points on the motherboard.
What is the Primary IDE Master?
If you have a single IDE cable, with two hard drives on it one must be set to master and one to slave. The master is the first or primary, hard drive and the slave is the second, or secondary drive.
Are IDE and PATA the same?
Well, one part of this is easy: IDE and PATA are two names for the same thing. The rest – well, the easy part is that SATA and PATA are two different ways of connecting a hard drive to your computer.
What is the difference between 80-conductor and old 80- conductor cables?
Connector Assignments and Color Coding: For the first time, the 80-conductor cable defines specific roles for each of the connectors on the cable; the older cable did not. Color coding of the connectors is used to make it easier to determine which connector goes with each device:
How many wires are there in an IDE cable?
The cable has 40 wire connectors in it, and usually has three identical female connectors: one is intended for the IDE controller (or motherboard header for PCs with built in PCI ATA controllers) and the other two are for the master and slave devices on the interface.
What is the difference between ATA and IDE cables?
IDE is the old ATA, now called PATA, in contrast to the newer SATA. IDE for 3,5″ (and 5,25″, like the Quantum ‘Bigfoot’ and CD-ROM) drives use the 40 pin cables mentioned in the article. IDE for 2,5″ drives use 44 pin connectors.
What is the purpose of the stripe on the IDE cable?
The stripe is used to line up pin 1 on the controller (or motherboard) with pin 1 on the devices being connected, since the techniques used for keying the cables are not standardized. A standard, 40-wire IDE/ATA cable. Note the presence of three black connectors, and the 40 individual wires in the ribbon cable.
